Dyna-Glo KFA80H - Specifications

H
WD
32.0"(813mm) 11.7"(297mm)
16.7"(424mm)
17
13. SPECIFICATIONS
KFA50H/80H Models
KFA135H/220H Models
KFA135H KFA220H
D
41.9”(1,063 mm) 47.4”(1,205 mm)
W
21.5”(547 mm) 23.1”(587 mm)
H
32.4”(824 mm) 33.5”(850 mm)
MODEL KFA50H KFA80H KFA135H KFA220H
BTU/Hr.
HIGH 50,000 80,000 135,000 220,000
LOW N/A N/A N/A 180,000
Fuel Consumption
- Gal./Hr(

./Hr)
HIGH 0.38(1.44) 0.60(2.27) 1.02(3.86) 1.66(6.28)
LOW N/A N/A N/A 1.36(5.15)
Fuel Tank Capacity - Gal.(

)
5.0(18.9) 5.0(18.9) 10.0(37.9) 13.0(49.2)
Fuel Tank Capacity
- Gal.(kgf/cm
2
)
HIGH 3.8(0.27) 3.8(0.27) 5.5(0.39) 8.5(0.60)
LOW N/A N/A N/A 6.5(0.46)
Volt/Hz 120Vac/60hz 120Vac/60hz 120Vac/60hz 120Vac/60hz
Amps. 1.6 1.6 2.5 3.7
Phase 1 1 1 1
Size(D×W×H), Inch(mm)
32.0×11.7×16.7
(813×297×424)
32.0×11.7×16.7
(813×297×424)
41.9×21.5×32.4
(1,063×547×824)
47.4×23.1×33.5
(1,205×587×850)
Weight Lbs.(kg) 26.9(12.2) 26.9(12.2) 52.2(23.7) 60.2(27.3)
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
