3
Figure 2. KFA135H MODEL
Figure 3. KFA220H MODEL
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
Power Cord
(Piggy Back)
Rear Handle
Cord Wrap
Pressure Gauge
Fan Guard
Fuel Drain Bolt
Front Handle
Upper Shell
Hot Air Outlet
Shell Lower
Fuel Gauge
Fuel Cap
Side Cover
Lamp
Thermostat Knob
Room Temp. Display
Power/Reset Switch
10” Flat Free Wheel
10” Flat Free Wheel
Front Handle
Upper Shell
Rear Handle
Cord Wrap
Pressure Gauge
Fan Guard
Fuel Drain Bolt
Power Cord
BTU Control Switch
Hot Air Outlet
Shell Lower
Fuel Gauge
Fuel Cap
Side Cover
Lamp
Thermostat Knob
Room Temp. Display
Power/Reset Switch
(Piggy Back)
