DYNACO Stereo 80 User Manual

Stereo 80 Specifications
POWER OUTPUT 40W per channel into 2, 4, or 8 ohms
POWER BANDWIDTH: 40W from 17Hz to 75kHz (-3dB points)
THD < 1% @ full power @ 1kHz<.05% @ 1W @ 1kHz, matched output tubes
FREQUENCY RESPONSE 2Hz to 60kHz (-3dB points)
INPUT SENSITIVITY .3V for full power output (Input Sensitivity Control set to maximum)
INPUT IMPEDANCE 50k
SLEW RATE 30V/µS
SIGNAL-TO-NOISE RATIO 90db below full output
TUBE COMPLEMENT two 12AT7, two 6DJ8, four EL34
POWER CONSUMPTION: 210 Watts
AC LINE VOLTAGE 100V, 120V, 220V, or 240V @ 50/60 Hz
DIMENSIONS 17” Wide, 7.75” High, 15” Deep
SHIPPING WEIGHT 42 lbs
WARRANTY Three years - parts and labor. (one year on tubes)
16
