Stereo 80 PC Board Parts List (cont.)
Semiconductors
2.5A, 1KV D1 through D11
1N5242B (12V, 1/2W Zener) ZD1, 4, 7, 10
1N 5388 (200V, 5W Zener) ZD2, 3, 5, 6, 8, 9, 11, 12
3506 (35A, 600V Bridge Rectifier) FWB1
IRF 830 (N-channel FET) Q1, 2, 3, 4
7812 (TO-220) [LM78M12CT] U1
7815 (TO-220) [LM78M15CT] U2
LED (red, T-1 3/4 type) LED5, 6
LED, 2-color (2-term, T-1 3/4 type) LED1, 2, 3, 4
LM339 (Quad Comparator) U3, 4
Tubes
Tube, 12AT7 V1, 5
Tube, 6DJ8 V2, 6
Tube, EL34 V3, 4, 7, 8
Misc.
Tube Socket - 9-pin, PCB mount for V1, 2, 5, 6
Tube Socket - 8-pin, PCB mount for V3, 4, 7, 8
Switch, DPST, (AC Power) SW1
Switch, SPDT, (Triode/Ultralinear) SW2
Switch, SPST, (Bias Lamps) SW3
Relay, 12V, DPDT K1, 2
Ferrite Beads FB1 through FB8
Choke, .32 henry @ 360ma L1
Fuse, 7A fast-blow (100 and 120VAC)
3.5A fast-blow (220 and 240VAC)
F1 (in power entry module)
Heat Sink - Thermalloy P/N 7019B-MT HS-1 through HS6
Heat Sink - Thermalloy P/N 7025B-MT HS7, 8
Heat Sink - for U1 HS9
Power Transformer T1
Output Transformer T2, 3
Audio PC Board Dynaco P/N 17-0421-P
Bias Light PC Board Dynaco P/N 17-0422-P
Input PC Board Dynaco P/N 17-0459
