13
15. Install LED Light Up Case Batteries
(Note: Batteries not included)
. Take out the LED light up case (already
assembled at factory) from the package.
. Loosen the screw on back of the LED
case and remove the cover.
. Then insert 3 x 1.5V size AA AM-3 or
LR6 batteries as shown.
. Replace the cover and tighten the screw
to secure it in place.
No
te: Please refer to page 11 for battery safety information.
16. Install LED Light Up Case
. Slide the LED case into the slot on rear
vehicle body as shown, push until you
hear a “click” sound to ensure it is securely
attached. (Push the case all the way down
to the end of the slot).
No
te: The LED light up case is removable,
and can be taken off easily for child to
play. (Just pull the case up to remove.)
14. Rear Rack Assembly
. Take out the rear rack (assembled with one
support already) from the bottom of the vehicle
body, then fit the unassembled support in the
slots of the rear rack as shown, insert two
4x12 round head screws and tighten them
securely with a screwdriver.
. Fit the rack in the slots at rear of vehicle body
as shown.
. Insert the rear rack into the vehicle body as
shown until you hear a “click” sound to ensure
the rear rack is securely attached.
17. Installation of the tail light
. Distinguish left and right tail lights,
“L” on back) into left hole and right tail
right hole on back of the vehicle body
Push until you hear they click into place.
as shown in below diagram.
light (marked with “R” on back) into
and insert left tail light (marked with
To Next Page
