Dynamo Power DP7100 - Generator Parts List Continued

GENERATOR PARTS DIAGRAMS AND LISTINGS
No
Part Description QU.T
-1
Part Code
47
clamp of accumulator with bolt and nut 2
6500S-E-047
48
cover of clamp of accumulator 2
6500S-E:048
49
Alternator assembly 1
6500S-E-049
50
Output wind leading shaft
1
6500S-E-050
51
Manostat
1
6500S-E-051
52
Gasket of output bore
1
6500S-E-052
53
Diesel engine
1
6500S-E-A53
54
Capacitor/AVR
1 I
6500S-E-054
55
Intake wind leading shaft
1
6500S-E-055
56
Pressing plate of high pressure fuel pipe
1
6500S-E-056
57
shock preventing mat of intake wind leading shaft
1
6500S-E-057
58
shock preventing holder of intake wind leading shaft
1
6500S-E-058
59
Cover of wheel
4
6500S-E-059
60
Fuel leak-off pipe of pipe tee 9
1
6500S-E-060
61
Pipe tee
1
6500S-E-061
62
Fuel inlet pipe of pipe tee 13
1
6500S-E-062
63
Support of manostat
1
6500S-E-063
64
lead of manostat
1
6500S-E-064
65
Electromagnet
1
6500S-E-083
66
Accelerator electromagnet
1
6500S-E-084
67
Pulling wire for turn-off
1
6500S-E-085
68
Pulling wire for throttle
1
6500S-E-086
69
Pulling role for accelerator
1
6500S-E-087
70
Remote starter
1
6500XER-F-056
A
Bolt M6
x
16with flat washer
54
6500S-E-065
B
Heterotypic bolt M6
x
8
6
6500S-E-066
C
Heterotypic bolt M6
x
14
6
6500S-E-067
D
Heterotypic bolt M6
x
22
6
6500S-E-068
E
Bolt M10
x
45with flat washer and spring washer
4
6500S-E-069
F
Bolt M6x16
4
6500S-E-070
G
Bolt M8x25
5
6500S-E-071
H
Bolt M6x12
17
6500S-E-072
I
Bolt M5x8
2
6500S-E-073
J
Heterotypic nut M6
34
6500S-E-074
K
Nut M8 with flat washer 8and spring washer 8
6
6500S-E-075
L
Nut M10with flat washer 10and spring washer 10
wawasherwas110(1)10
12
6500S-E-076
M
Bolt M5x12
2
6500S-E-077
N
Bolt M6x22
2
6500S-E-078
O
crossed bott M4x22 with flat washer and spring
washer
5
6500S-E-079
P
Nut M4
5
6500S-E-080
Q
crossed bolt M5x12
4
6500S-E-081
R
Nut M5
4
6500S-E-082
* Please notice that Item 65,66,67,68 and 69 only can be supplied to the generators
with mechanical injection pump. If you use electromagnetic pumps, these parts are
not necessary. Please consult the dealer before make the orders.
