Dynamo Power DP7100 - Generator Parts Diagrams and Listings; Parts List (Table 5-1)

GENERATOR PARTS DIAGRAMS AND LISTINGS
Table 5-1. Please refer to figure 5-1 for illustration
No
Part Description Quantity
Part Code
1
Silencer cover 1
6500S-E-001
2
Silencer bend
1
6500S-E-002
3
Left board of cover
1
6500S-E-003
4
Back door of cover
1
6500S-E-004
5
Fixing sleeve for observing bore
1
6500S-E-005
6
Fixing sleeve for input of fuel tank
1
6500S-E-006
7
Main cover
1
6500S-E-007
8
Switch of front door
1
6500S-E-008
9
Air filter baffle
1
6500S-E-009
10
stationary rings of generators
1
6500S-E-010
11
Right board of cover
1
6500S-E-011
12
Output panel assembly
1
6500S-E-012
13
Cover of observing bore for air filter
1
6500S-E-013
14
Cover of fuel tank assembly
1
6500S-E-014
15
Buoy for oil level indication
1
6500S-E-015
16
Fuel tank(not assembly)
1
6500S-E-016
1
17
Lining of absorbing mat
4
6500S-E-017
18
Shock absorbing mat
4
6500S-E-018
19
Clip 9
4
6500S-E-019
20
Clip 13
4
6500S-E-020
21
Fuel inlet pipe I (13)
1
6500S-E-021
22
Fuel filter assembly with cover
1
6500S-E-022
23
Fuel inlet pipe II ( 13)
1
6500S-E-023
24
Fuel leak-off pipe
1
6500S-E-024
25
Cover of U-type chamfer
1
6500S-E-025
26
U- type chamfer
1
6500S-E-026
27
Support of U-type chamfer
1
6500S-E-027
28
Moire output pipe
1
6500S-E-028
29
Gasket of silencer
1
6500S-E-029
30
Upper silencer
1
6500S-E-030
31
Low silencer
1
6500S-E-031
32
Back cover of alternator
1
6500S-E-032
33
Bracket of classis
1
6500S-E-033
34
Shock absorbing mat of generators
4
6500S-E-034
35
Tow structure
1
6500S-E-035
36
Rectify bridge
1
6500S-E-036
37
Wiring seat 3
x
2
1
6500S-E-037
38
Battery cable(set)
1
6500S-E-038
39
Chassis
1
6500S-E-039
40
Rolling wheel on chassis(4 inch)
4
6500S-E-040
41
Flat washer
8
6500S-E-041
42
Pin 3x25
4
6500S-E-042
43
Motherboard of accumulator
1
6500S-E-043
44
Accumulator (maintenance free)
1
6500S-E-044
45
hook type bolt of battery
2
6500S-E-045
46
Pressing plate of accumulator
1
6500S-E-046
