Dynamo Power DP7100 - 1-2 Technical specifications and data

TECHNICAL SPECIFICATIONS AND DATA
1-2 Technical specifications and data
Table 1 The Single-cylinder diesel generator
Item Model DP7100
Generator data
Generator
technical
data (AC)
Frequency (HZ) 60
60
Rated power (kW)
5.0
Peak power (kW)
6.3
Voltage (VAC)
120/240
Phase type
Single phase
Power factor (cos)
1.0
Speed (rpm)
3600
Excitation
self-excitation , Brushless
Voltage regulator
Capacitor
Continuous operation time (Hr. by half load)
Continuous run for 12 hours
Noise level [dBA/7m] (zero load
—
full load)
69-74
Connection
Rigid connection driven shaft
Dry weight (kg)1(1b)
Gross weight(ks) /(1b)
160 / 353
180 / 395
Dimensions (L
x
W
x
H)(mm)/(inch)
929 x 538 x 724 / 36.6 x 21.2 x 28.5
Engine
Engine type
Single cylinder,
4-stroke,air-cooled,vertical,
diesel engine
Fuel type
0# (summer), —10# (winter),
—35#(chill cold) diesel
Lube oil brand
CD or better than CD
Output
I Continuous (kW)
Output
Bore x
stroke
(mm)
/(inch)
Max Output(kW)
5.8
86x72 / 3.39x2.83
6,3
Displacement (cc) /(cub inch)
418 / 25.5
Compression ratio
19:1
Lube-oil capacity (L) /(Gal)
1.65 / 0.43
Fuel tank capacity (L) /(Gal)
14.5 / 3.8
Starting system
Electric start/Remote start
Note: Allow 30 hrs initial run time for max efficiency.
