6 CA 262/362/512 M262EN2
Opening pressure,
MPa (psi) CA262/362 CA512
Drive system 38,0(5,500) 38,0(5,500)
Charge system 2,0(290) 2,0(290)
Vibration system 40(5,800) 37,5(5,400)
Steering system 18,0(2,600) 18,0(2,600)
Brake release 1,4(200) 1,4(200)
TECHNICAL SPECIFICATIONS
Tightening torque
Tightening torque in Nm (lbf.ft) for oiled, bright
galvanized bolts tightened with a torque wrench.
Hydraulic system
Bolt size: M24 (P/N 90 39 64)
Strength class: 10,9
Tightening torque: 800 Nm (590 lbf.ft)
(for Dacromet treated)
ROPS
ROPS bolts must always be tightened dry.
M STRENGTH CLASS
thread 8.8 10.9 12.9
M6 8,4 (6.2) 12 (8.9) 14,6 (10.8)
M8 21 (15.5) 28 (20.7) 34 (21.1)
M10 40 (15.5) 56 (41.3) 68 (25.1)
M12 70 (51.6) 98 (72.3) 117 (86.3)
M16 169 (124.7) 240 (177) 290 (213.9)
M20 330 (243.4) 470 (346.7) 560 (413.1)
M24 570 (420.4) 800 (590.1) 960 (708.1)
M30 1130 (833.5) 1580 (1165.4) 1900 (1401.4)
M36 1960 (1445.7) 2800 (2065.3) –
Air conditioner (Optional)
The system described in this manual is of the ACC
type (Automatic Climate Control), ie, a system that
maintains the set temperature in the cab, on condition
that windows and doors are kept closed.
Refrigerant designation: HFC-R134:A
Weight of refrigerant when newly filled CA262/362/
512=1600 gram
