P/N 35 84 70
30 Hydr Propulsion Pumps CC 102/102C/122/122C W-1012-2EN
Pump assembly
1. Insert bearing cup set.
2. Assemble bearing, wire.
Assistance: Use bearing with grease
or fix the bearing with rubber ring.
3. Rubber ring.
4. Insert completely swivel cradle into the
housing. Pay attention for correct seat
of the swivel cradle in the housing.
5. Remove rubber ring.
