P/N 35 84 70
W-1012-2EN Hydr Propulsion Pumps CC 102/102C/122/122C 41
Adjustment instructions
Low pressure valve (Charge pressure)
Attention!
Observe safety regulations!
Note:
Readjusting only at operating
temperature.
Connect manometer to "G".
Attention!
Charge pressure setting!
Nominal pressure p
H
- 18 bar
Peak pressure p
H
- 40 bar
at max. speed.
Note:
Adjusting data according to order.
