English - 18 -
12.2.- TRANSMITTER:
RF power: 15 W (AM) / 45 W (FM) / 60 W PEP (SSB).
Current: 12 A (with modulation).
Modulation: FM/AM/USB/LSB.
Intermodulation distortion: SSB: 3
rd
order >-25 dB; 5
th
order >-35 dB.
SSB carrier suppression: 55 dB.
Unwanted sideband: 50 dB.
Frequency response: 300 to 3000 Hz (AM/FM).
450 to 2500 Hz (SSB).
Antenna impedance: 50 Ω.
12.3.- RECEIVER:
Sensitivity: SSB: 0.25 μV for 10 dB (S+N)/N.
AM: 1.0 μV for 10 dB (S+N)/N.
FM: 1.0 μV for 20 dB (S+N)/N.
(At greater than 1/2 W to audio output).
Adjacent channel selectivity: AM/FM: 60dB / SSB: 70 dB.
Image rejection: >65 dB.
IF frequencies: AM/FM: 10.695 MHz (1
st
IF); 455 kHz (2
nd
IF).
SSB: 10.695 MHz.
RF gain control: 45 dB adjustable for optimum signal reception.
Automatic gain control (AGC): <10 dB change in audio output for inputs from 10
to 100.000 μV.
Squelch: Adjustable; threshold less than 1.0 μV.
Automatic squelch control (only AM/FM) 1.0 μV.
Audio output power: 3 W @ 8 Ω.
Frequency response: AM/FM: 300 to 3000 Hz; SSB: 450 to 2500 Hz.
Built-in speaker: 8 Ω, round.
External speaker (not supplied): 8 Ω, disables internal speaker when connected.
