CONNECTION AND COMMISSIONING
Connection of an additional active subwoofer
If desired, you can connect an active subwoofer to
the cinch socket "Output SW" (10) at the rear of the
unit, which should receive the volume controlled
stereo output level (line level) of the currently
selec ted source. The output level of the pre-ampli-
fied output "Output SW" (10) depends on the volu-
me setting and the insertion of headphones.
Connect this signal output to the signal input
("LINE IN"/"INPUT" etc.) of the active subwoofer
using a standard mono cinch cable.
Connecting headphones
Headphones equipped with a 6.3 mm jack plug can
be plugged into the "Headphone" jack (6) on the
front of the unit. All headphones with an impedance
between 32 and 600 Ohm can be used. Unsuitable
low impedance headphones can damage the unit or
produce unexpectedly high-volume levels that can
damage your hearing. As long as headphones are
plugged in, the speakers are turned off. As a pre-
caution, the volume on the "VOLUME" knob (2)
should be reduced before inserting and tightening
the headphones (these knobs are also used to
adjust the volume of the headphones).
Connecting the speakers
To connect your speakers to the TV-50, use cables
with a sufficient cross-section. Ensure that bare
speaker wires never touch each other or the back
of the casing! Do not connect any active loudspea-
kers! Only use loudspeakers with a nominal impe-
dance of 4 - 8 Ohm. Using speakers with a different
nominal impedance will damage the amplifier. For
each speaker (R: right or L: left) you will find two
speaker screw terminals (positive + and negative -)
on the device (11), which are connected to one side
