37
9. Headphone-Anschlussbuchse ( )
This 3,5mm jack plug allowes the use of a headpho-
ne with a impendance of 32 - 600 Ohm.
10. SD
Jack for SD memory.
11. USB
Jack for USB memory.
12. TREBLE
Regulates the high tone content of the output
signal.
13. BASS
Regulates the low tone content of the output
signal.
14. A, B, A/B
Regulates the signal output of the speaker connec-
tions (19). With the switching positions A and B
you’re able to turn on and off the outputs „SPEA-
KER A“ and „SPEAKER B“. With the switching posi-
tion A/B, under usage of suitable speakers (8 - 16
Ohm), you’re able to use both outputs „SPEAKER A“
and „SPEAKER B“ at once.
15. AUX1/AUX2/AUX3
Input selector for signal entrances AUX 1 (16), AUX2
(17) und AUX3 (SD[10] / USB[11] / BT).
