DL5.0C Pro User Manual
©Dyness reserves the copyright of this document
7
Item
Name
Definition
1
Positive socket
Battery output positive or parallel positive line
2
ADD
DIP switch
3
SW (battery
wake/sleep
switch)
When the "OFF/ON" switch button is in the ON state,
press and hold this button for 3 seconds to put the
battery into the power-on or off state.
4
SOC
The number of green lights shows the remaining power.
Table 2-7 for details.
5
ALM
Red light flashing when an alarm occurs, red light always
on during protection status. After the condition of trigger
protection is relieved, it can be automatically closed.
6
RUN
Green light flashing during standby and charging mode.
Green light always on when discharging.
7
CAN
Communication cascade port, support CAN
communication (factory default CAN communication)
8
485
Communication cascade port, support RS485
9
DRY CONTACT
/
10
Negative socket
Battery output negative or parallel negative line
11
Grounding
Shell ground connection
12
Power switch
OFF/ON, must be in the "ON" state when in use
13
Wifi
Remote upgrade program
14
LED light
Display battery SOC and warning information
Table 2-4 DIP switch definition and description
DIP switch position (master communication protocol and baud rate selection)
#1
#2
#3
#4
Define different protocols；
Distinguish between master and slave
Baud rate selection
OFF：CAN: 500K,485: 9600
ON
：
CAN: 250K,485: 115200
