Lower display: CO.MAX
Range: From 10.0 to 100.0%. This limit is active in manual and automatic mode.
Default value: 100.0
CONTROL OUTPUT MANUAL MODE INDICATION - Group 4
Available: Always.
Upper display: Control output manual mode indication.
Lower display: CO.MMI
Range: 100.0 / rPn Use this parameter to select how the controller shows the output value
in manual mode; in the range 0-100.0%, or scaled with CO.RH and CO.RL
parameters (RPM indication).
Default value: 100.0
DIRECT/REVERSE SELECTION FOR CONTROL OUTPUT - Group 4
Available: Always.
Upper display: Direct/reverse selection for control output.
Lower display: CO.D/R
Range: r d, r r, d d, d r. The first digit shows the relationship between input signal and
displayed output value. The last digit shows the relationship between displayed
output signal and output value.
Example:
Value Signal Input Output Displayed Output Control
r d 0 - 100 (increase) 100 - 0 (decrease) 100 - 0 (decrease)
r r 0 - 100 (increase) 100 - 0 (decrease) 0 - 100 (increase)
d d 0 - 100 (increase) 0 - 100 (increase) 0 - 100 (increase)
d r 0 - 100 (increase) 0 - 100 (increase) 100 - 0 (decrease)
Default value: r d.
LINE FREQUENCY - Group 4
Available: Always.
Upper display: Line frequency rejection.
Lower display: LINE.F
Range: 50, 60. 50 Hz. 60 Hz.
Default value: 50.
LOADING DEFAULT DATA - Group 4
Available: Only if access to level c is allowed.
Upper display: OFF
Lower display: DEFLT
