CHAPTER 2
Support Arm and Monitor Tray Installation
Above Ground Model 250i Motorcycle Dynamometer Installation Guide
2-26
SUPPORT ARM AND MONITOR TRAY INSTALLATION
This articulated arm and platform supports the monitor, keyboard, and mouse in a
convenient position for operation while seated on the motorcycle. The support arm
can be mounted on either side of the dynamometer.
You will need the following parts:
• 61329101P Monitor Tray
The following parts are included in P/N 61329003:
• 61329500 Support Arm Upright
• 61329100 Monitor Arm (2)
• 26215520 Washer, 1.87 x 1.25 x 12 (3)
• 35521420 Cap Plug (4)
INSTALLING THE SUPPORT ARM AND TRAY
The support arm and monitor tray may be installed on either side of your dyno.
1 Remove the four 3/8-16 x 1/2-inch button-head flange screws from the dyno
where you plan to install the support arm.
2 Using an allen wrench, secure the support arm to the dyno frame with four
3/8-16 x 1/2-inch button-head flange screws you removed earlier.
3 Place a poly washer around the pin of the first arm and insert the arm into the
support arm.
4 Place a poly washer around the pin of the second arm and insert the arm into the
first arm.
5 Place a poly washer around the pin of the tray and insert the tray into the second
arm.
6 Insert a plastic cap in both ends of each arm.
7 Check for clearance between the monitor arm and motorcycle, walls, ceiling, etc.
Note: Dynojet does not recommend placing the computer CPU on the
monitor/keyboard tray since vibration can cause damage to the computer.
