Dyson Purifier Humidify+Cool User Manual

Getting started
Deep clean cycle button
Stand-by button
Amplifier loop
Outer cover
release buttons
Outer cover
Water tank
release buttons
Stand-by
Auto purify mode
Airflow speed
Oscillation
Sleep timer
Information menu
Auto humidify mode
Humidity control
Airflow direction
Night mode
The layout of the remote control with the standby button on the top left, the Auto purify mode button below, then the
Airflow speed toggle up and down button. Below that is the Oscillation button and finally at the bottom is the Sleep timer
button. On the top right-hand side is the Information menu button, then going downwards, the Auto humidify mode
button, humidity control toggle button, Airflow direction and then Night mode button at the bottom.
Image of the machine with the location
of parts labelled.
The large oval loop making
up the top of the machine.
Two push down buttons
located either side of the
main body of the machine.
The mesh cover on the
bottom of the machine is
intwo parts, front and back.
The buttons to remove the
water tank are located on
both sides, just above the
bottom of the machine.
The top, of the two buttons
located on the main body of
the machine just below the
loop amplifier, is the Deep
clean cycle button.
Below the Deep clean
cycle button is the
standby button.

Dyson Purifier Humidify+Cool Specifications

General

Package width	350 mm
Package height	1000 mm
Package weight	12120 g
Filter life (max)	12 month(s)
AC input voltage	240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	43.4 W
Display type	LCD
Product color	Silver, White
Housing material	Acrylonitrile butadiene styrene (ABS)
Airflow	43.5 l/s
Noise level	62.4 dB
Air purify rate	- m³/h
Number of speeds	10
Country of origin	Malaysia
Oscillation angle	90 °
Suitable for room area up to	- m²
Suitable for room volume up to	81 m³
Harmonized System (HS) code	8421392590

Weight and Dimensions

Depth	312 mm
Width	220 mm
Height	923 mm
Weight	8050 g
