Model Assembly
Connect the clevises to the control horns as shown
1.
2.
3.
4.
Elevator Ailerons Rudder
Arms
tooltip
tooltip
tooltip
Horns
tooltip
tooltip
tooltip
The illustration shows recommended hole settings in the servo arms
and control horns.
Control Horn and Servo Arm Settings
