9E-flite F-15 Eagle ARF Assembly Manual
6. Snap the ball link on the 145mm pushrod onto the
stabilizer control ball end.
7. Slide the pushrod connector onto the pushrod wire.
After centering the elevator servo using the radio, install
the servo arm on the elevator servo. Make a small bend
in the pushrod to ensure the pushrod is straight and in
line with the control arm.
