CHAPTER 7
ANALYZER SETUP
The SETUP MENU allows the operator to change system parameters.
Every parameter listed on the SYSTEM MENU screen can be changed as follows:
a. Use the UP / DOWN keys to move the highlighted line to the parameter you wish
to change.
b. Press OK to edit the value. The arrow will disappear as the current line shifts to
the left by one character and a cursor appears over the value. This indicates that
you are in edit mode.
c. Use the UP / DOWN keys (buttons displaying the triangles) until the desired
value of the selected parameter appears on the display.
d. Press the OK key to execute the change.
OCT 1 ‘15 12:45:00
Fuel: NATURAL GAS
Temperature Units: F
Measure Units: PPM
Pressure Units: inWC
O2 Reference: TRUE
Dilution Duty: 90%
Water Drain: 25min
Chiller Duty: 70%
Dilute CO: 5000 PPM
Use CO-IR: 7000 PPM
Thermal Eff: 0.25
Baudrate: 9.6 kbps
Velocity Units: FPS
Stack Size: 144 in
2
Version: 1.01
Battery: x.xx V
To Next Page
