CHAPTER 2
THE INSTRUMENT KEYBOARD
A brief explanation of the instrument’s buttons is as follows:
CALIB
Controls calibration settings and zeroing of the analyzer’s sensors.
SETUP
Controls all customization parameters (such as measurement units)
for the analyzer
MEASURE
Displays the analyzer’s currently measured data in either of two fonts:
A. Small fonts (all data displayed simultaneously plus range indicated,
battery condition and time)
B. Large fonts (four data parameters displayed simultaneously)
POWER
Turns analyzer and conditioning system on and off
STORE
Controls operation of the analyzer’s internal data storage
P
RINT
Executes print commands for the analyzer’s remote printer
OK
Used with the direction keys to change a setting or navigate the
menus
▲
Moves the cursor up or increments the entry marked by the cursor
▼
Moves the cursor down or decrements the entry marked by the cursor
◄
Moves the cursor to the left
►
Moves the cursor to the right
