E8500 Instruction & Operations Manual
version 1.017
Page 32 of 49
LOG INTERVAL: This selects the interval between each log entry. The interval can be
set between 1 and 60 seconds.
PRINT BUFFER: This option is used to print data stored in the analyzer’s memory.
Each line corresponds to one storage tag. Tags containing data show an icon next to
the index number. When you scroll up and down, the date (mm/dd) and time (hh/mm)
when the data was stored appear at the bottom; empty tags show the word “empty”. To
print the contents of a specific tag, use the UP / DOWN keys to move the arrow to the
desired tag and press OK. If you wish to print all of the analyzer’s stored data in
sequence, move the arrow to the entry ALL TAGS and press OK.
CONFIGURE RECORD: This option allows the user to add, delete, or change the order
of the parameters that appear on the paper print out.
EDIT CUSTOMER NAME: This will display a screen
where you can change the information printed at the top of
each printout. Usually the customer’s name or the
operator’s name appears here. To edit this information,
use the UP / DOWN / LEFT / RIGHT keys to navigate
around the keyboard, and press OK to select the letter or
number. For lower-case letters, highlight shift and
press OK, for symbols, highlight sym and press OK. The
arrows in the corner will move the cursor forward or
backward through the name.
CALIBRATION RECORD: This option will print a record of each sensor’s last
calibration, including the date of calibration and span gas value used.
PAPER FEED: This toggles the printer’s motor on and off, advancing the paper out the
top of the analyzer as needed. The motor will not turn on if there is no paper present.
** EDIT HEADER INFO *
E INSTRUMENT ANALYZER
1 2 3 4 5 6 7 8 9 0 ◄
A B C D E F G H sym ►
Q R S T U V W X Y Z
