TROUBLESHOOTING & DIAGNOSTICS
Read all of this manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notices, Cautions, Warnings, and Dangers.
Page O-6 Repair and Service Manual
OUTPUT FUNCTIONS (18 - 19)
18.REVERSE WARNING BUZZER: displayed as ’BUZZER’, the next
line displays the buzzer state as ’ON’ or ’OFF’.
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
19.SOLENOID: displayed as ’SOLENOID’, the next line displays the
solenoid state as ’ON’ or ’OFF.
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
BRAKE FUNCTIONS (20)
20.ELECTRIC BRAKE CURRENT: displayed as ’EBRAKECURR’, the
next line displays the brake current as a three place decimal in Amps;
the brake current displayed below is 3 milliAmps.
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
DIAGNOSTICS REPORT (real - time read only)
BATTERY FUNCTIONS - REAL TIME (1 - 4)
1. BATTERY VOLTAGE: displayed as ’VOLTAGE’, the next line displays
’HIGH’, the actual voltage to a 10th of a volt, or ’LOW’ and voltage to
10th of a volt.
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
_______________________________________________________
LSV DIAG REPORT
BUZZER
OFF
SOLENOID
ON
E
BRAKE CU
R
0.003 A
LSV DIAG REPORT
BUZZER
OFF
SOLENOID
ON
E
BRAKE CU
R
0.003 A
LSV DIAG REPORT
BUZZER
OFF
SOLENOID
ON
EBRAKE CUR
0.003 A
LSV DIAG REAL TIME
BATT VOLT
48.71 V
CALC CURR
1.4 A
SOC COND
59 %
