Note: In the remote control, the power of 25 corresponds to
the actual 25 mW, 200 corresponds to the actual 100 mW, and
500/800 corresponds to the actual 200 mW.
5.0 Switchable VTX
6.0 Camera
Case size: 19mm*19mm
Weight: 9.5g
Total pixels: PAL: 1020H×596V (0.61MP);
NTSC: 1020H×508V (0.52MP)
Effective pixels: PAL: 976H×582V (0.57MP);
NTSC: 976H×494V (0.48MP)
Signal system: PAL/NTSC switchable
Resolution ratio(horizontal center): 700TVL
Video output: 1.0Vp-p/75Ω
Automatic gain control: 0.25/0.50/0.75/1.00, up to 55dB
White balance: off
Exposure mode: electron exposure
Electronic shutter: 1/50(1/60) - 1/100000 S
Gamma correction: 0.45/1.0
Synchronization method: inter-sync
Camera lens: standard 2.1mm
Lens operating voltage: DC 5-12V
Working current: 70mA (low power consumption)
Working temperature: -20℃~ - 60℃
Humidity: 0%~98%
-9-
