Eagle Access Control Systems EAGLE Open - Wiring Configurations; Option 1: Two Different Gates; Option 2: Two Different Modes

2
WIRE IT UP
Beforeinstalling EAGLEOpen, pleasestudy the user guide
of your main access control unit, with particular regard
to the chapteron accessory connections, andcompareit
with this UserGuide andthe connection drawing therein.
IN1 IN2
POWERSUPPLY
OUT1
OUT2
GATE2
GATE1
OPTION1-TWO DIFFERENT GATES
MAINCONTROL UNITMAINCONTROL UNIT
IN1 IN2
POWERSUPPLY
OUT1 OUT2
PARTIALOPEN
MODE
FULLOPEN
MODE
OPTION2-TWO DIFFERENT MODES
MAIN CONTROL UNIT
*Theusage of the input is optional,can be enabled/disabled in the application.
10 11
