7. EXPLOSIVE VIEW 8
Item Part No. Description
LD01 B-004-100001-0 Nut M10
LD02 B-040-102020-1 Flat Washer 10
LD03 B-010-100251-0
Hex Socket Head Bolt
M10×25
LD04 CC-0LD-020000-0 Complete Up Support
LD05 CX-0LD-010100-0 Tire Lifting Support
LD08 CC-0LD-030000-0
Complete Down
Support
LD09 B-014-121101-0
Outer Hex Bolt
M12×110
LD10 CA-005-000001-D
Complete Rise-Fall
Cylinder
LD11 CX-0LD-010500-0 Support Rod
Item Part No. Description
LD12 C-0LD-010406-0 Connection Bolt
LD13 B-040-102020-1 Flat Washer 10
LD14 B-004-100001-0 Nut M10
LD15 CC-0LD-060300-0 Tire Lifting Rod
LD16 CC-0LD-060100-0
Tire Lifting Support
Board
LD18 B-055-160001-0 Snap Ring 16
LD20 CX-0LD-010405-0 Rise-Fall Pin
LD21 B-014-161201-0
Outer Hex Bolt
M16×120
LD22 CX-0LD-010400-0 Lifting Arm
LD23 B-001-160001-0 Self-Locking Nut M16
LD24 B-040-162820-1 Flat Washer 16
