7
KEYBOARD
The keyboard has keys arranged in two vertical columns beneath the
arrow keys. The menu key near the bottom left corner of the keyboard
activates the first menu page. The other keys are used to activate the
alarm menu, make menu selections, and change modes.
MODE - Pressing this key switches the unit between different sonar
modes.
MENU - Press this key to show the menus and gain access to most
functions.
ARROW KEYS - These keys are used to make menu selections and to
move objects on the screen.
ZOUT, ZIN - These keys let you zoom the screen in and out to see detail.
ALARM - Press this key to activate any of the sonar alarms.
PWR - This key turns the Ultra Classic and it's lights on and off.
ENT, EXIT - These keys let you enter or erase values.
Ultra
Classic
PWRENT
MENU EXIT
MODE ALARM
ZOUT ZIN
