EarthWise SN72018 - Page 5

PRODUCT SPECIFICATIONS
Model: SN72018
Power supply voltage: 120V-60HZ Clearing width: 18 inches (460 mm)
Idle speed: 2000 RPM Max clearing depth: 12 inches (305 mm)
Power consumption: 13.5 Amp Clearing capacity: 700 pounds/minute
Weight: 31 pounds Throwing distance: Up to 30 feet
5
PARTS LIST
No. Description
1 Upper handle
2 Bail wire
3 Switch button
4 Cable clip
5 Crank handle
5A Upper crank
5B Lower crank
6 J bolt
7 Knob
8 Cable retainer
No. Description
9 Center handle
10 Cotter Pin
11 Auxiliary handle
12 Lower handle
13 Wheel assy.
14 Scraper blade
15 Auger
16 Side cover
17 Discharge chute
18 Chute deflector
