ASSEMBLY
6
UNPACKING
This product requires assembly.
Carefully remove everything from the box. Make sure that
all items listed in the packing list are included.
Inspect all items carefully to make sure no breakage or
damage occurred during shipping.
Do not discard the packing material until you have
carefully inspected and satisfactorily operated the snow
thrower.
PACKING LIST
- Snow Thrower
- Handle Assembly
- Chute Crank
- Chute Deflector
- Operator’s Manual
INSTALLING CENTER HANDLE
 Position the center handle and make sure the bracket
is pointed downward. (See Fig 1)
 Align the holes on the center handle with the holes in
the lower handle as shown. (See Fig 2)
 Insert J-bolt through both handles with the threaded
end at the bottom and facing inside. (See Fig 3)
 Install the handle knob and tighten securely to secure
the bolt in place. (See Fig 4)
 Repeat on the opposite side to secure the center
handle in place. (See Fig 5)
Fig. 1
Fig. 5
Fig. 4
Fig. 3
Fig. 1
Fig. 2
