9.3 Electronic control box
Note:The picture is for reference only, please refer to the actual product.
8/10kW
Main control board of hydraulic module
Inverter module
control board
(PCB A)
Main control board
of heat pump sysem(PCB B)
Inverter module
control board(PCB A)
Main control board
of heat pump sysem(PCB B)
4/6kW
Main control board of hydraulic module
