Easee Base - First Two Charger Backplates

23
B
B
B
B
Now attach the first 2 Easee chargers backplates to the
sides perpendicular to the column openings with 4 rounded
head screws each (8 screws total).
NOTICE! Pull the cable through the hole in the backplates
before attaching them.
3-Way / 4-Way
First
2 chargers
4
B
