Introduction
Easee Base
Conventions
This symbol indicates that the respective instructions must
only be carried out by an authorised electrician.
This symbol indicates an immediate danger to life and health
of persons due to the effects of electrical energy.
Non-observance of these instructions will result in serious
damage to health – up to and including life-threatening
injuries.
The Easee Base is a modular charging post for mounting up
to four Easee Charging Robots.
With Easee Base, it is possible to choose between four
different configurations. One-way setup where only one
charger is mounted, 2-way setup with two chargers, 3-way
setup with three chargers and finally 4-way setup where
there is a charger on all sides of the post.
With four configurations in one design, they share many
common parts. Only a few parts are specific to each type
of layout.
