25
If you are installing a 4-way setup, attach the last 2 Easee
chargers backplates to the column with 4 rounded head
screws each (8 screws total).
NOTICE! Before installing the electronics in the backplates,
they must all be programmed - please check the installation
guide that came with the Charging Robots.
4-Way
4-Way
Last
2 chargers
5
B
B
B
B
B
