easymaxx TS-20964R - Included in Delivery; Device Legend and Components

EN 14
Included in delivery
Check the scope of delivery for completeness and transport damage. If the device or
the power cord is damaged, do not use the device and contact customer service.
• Main unit
• Lid
• Lamella insert
• Cold air cover
• Activated carbon fi lter
• Filter cover
• Remote control
• Instruction manual
Two 1.5V type AAA batteries are additionally required for using the remote
control. These are not included in the delivery.
Legend
Device – front
1 Steam outlet
2 LED lights
3 Control panel
4 Housing
5 Lamella insert
6 Water tray
7 Silicone stopper for water tray (on the
bottom)
8 Cold air cover with adjustable ventila-
tion screen (removable)
9 Lid
10 Water tank (under the lid)
Device – front
11 Filter cover (removable)
12 Connection socket for adapter coaxial
power connector
13 Activated carbon fi lter (under the fi lter
cover)
14 Vents
Control panel
15 Indicator lights for fan speed
HI (High) – High speed
MED (Medium) – Medium speed
LO (Low) – Low speed
16 Humidifi er indicator light
17 Indicator light for LED lights
18 Remote control sensor
19 Operating light
20 Button
– on / off
21 Button
– LED lights
22 Button
– humidifi er
23 Button
– fan
Remote control
24 button – on / off
25 Lamp button – LED lights
26 Humidifi er button – humidifi er
27 Speed button – fan
