What to do if the #1 Fault LED and the #2 LED are turned on and the Eaton UPS beeps continuously?
This indicates that the Eaton UPS is overloaded or the load equipment is faulty. Check the loads and remove all non-critical equipment. Recalculate the load power and reduce the number of loads connected to the UPS. Also, check that the loads are not failed.
Why does my Eaton 10000HXL31 UPS battery discharging time diminish?
The battery discharging time diminishes because the battery might not yet be fully charged. Keep your Eaton UPS connected to utility power persistently for more than 10 hours to recharge the batteries. Also, the UPS might be overloaded, so check the loads and remove the non-critical equipment. Finally, the battery might be aged, and in that case you should replace the batteries.
Why is the utility power LED flashing on my Eaton UPS?
The utility power LED flashes because the voltage or frequency of the utility power is out of the input range of the Eaton UPS. The UPS is running in battery mode. To save your data and close the application program, make sure the utility power is within the input voltage or frequency range permitted by the UPS.
How to fix an Eaton 10000HXL31 that cannot power on?
If the Eaton UPS cannot power on, ensure that you press the “ON” button for more than 1 second. Also, check the battery or recharge the battery, as the UPS might not be connected to the battery or the battery pack voltage might be too low.
What does it mean when the #1 Fault LED and the #6 LED are on and the buzzer beeps on my Eaton 10000HXL31 UPS?
This means the Eaton UPS shutdown due to internal overheat. Make sure the UPS is not overloaded, the air vents are not blocked and the ambient temperature is not too high. Wait for 10 minutes for the UPS to cool down before turning it on again.
What to do if #1 Fault LED and #2 and #5 LED are on and the buzzer beeps on my Eaton 10000HXL31?
If the #1 Fault LED and the #2 and #5 LED are turned on, and the buzzer beeps continuously, it means that the Eaton UPS output is short circuited. Turn off the UPS, remove all the loads, and ensure that the load is not failed or the UPS has no internal faults before turning it on again.
Why won't my Eaton UPS turn on line mode when utility power is normal?
The bypass breaker may be in the “OFF” position. Set the bypass breaker to the “ON” position.
General| Real Power | 9000 W |
|---|---|
| Output Power Factor | 0.9 |
| Topology | Double Conversion Online |
| Form Factor | Tower |
| Frequency | 50/60 Hz |
| Power Rating | 10000 VA |
| Battery Type | Sealed Lead Acid |
| Communication Ports | USB, RS-232 |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Operating Humidity | 0% to 95% (non-condensing) |
| Input Voltage | 208/220/230/240 VAC |
| Output Voltage | 208/220/230/240 VAC |
Explains the system and model designation rules for the UPS.
Lists and explains the standard symbols used in the manual for user understanding.
Details the physical appearance and component layout of the UPS models.
Provides detailed technical specifications and performance data for the UPS.
Guides through unpacking, checking contents, and inspecting the UPS for damage.
Details requirements and procedures for connecting power cords and protective earth grounding.
Explains the process for connecting external batteries for extended backup time.
Describes how to connect multiple UPS units for redundancy and load sharing.
Covers turning the UPS on and off under different power conditions.
Explains the different operating modes: Utility, Battery, Bypass, and Abnormal.
Explains how to turn the UPS on and off using the front panel buttons.
Describes the Bypass, Utility Power, INV, Battery, and Fault LEDs.
Explains how LEDs #2-#6 indicate load capacity or battery level.
