35EATON 620 Mobile Open Circuit Piston Pump Service Manual E-PUPI-TS018-E2 November 2017
Assembly
15. Install gasket and bearing
Note: Lightly coat the steel side of the valve plate
with petroleum jelly for retention during assembly.
Install the valveplate over the bearing race aligning
the small slot on the outside of the valveplate with
the dowel pin in the End Cover.
Note: After Installation of Bearing, lubricate all
components with clean hydraulic oil.
14. Install valve plate
