Eaton 9372-FB-P Series Operating Instructions

40
D/GB
Technischer Anhang
Technical annex
Verdrahtungstabellen / Annex wiring tables
Größe/Size 9 430 x 650 x 284
I / A
Ø in mm²
1,5 2,5 4 6 10 16 25 35 50 70 95 120 150 185 240
3
6 1)
10 152
16 52 101 391
20 21 59 113
25 28 64 124
35 19 48 120
50 7 39 100
63 13 46 164 3)
80 18 51 184
100 22 48
125 2) 2 19 49
160 17 43
200 15 37 115
225 6 21 45
250 11 27 57
315 5 16 34
400 7 23
500 3
No. 246 246 206 154 124 102 78 78 34 26 26 11 11 9 9
Verdrahtungstabellen / Annex wiring tables
Größe/Size 10 430 x 650 x 437
I / A
Ø in mm²
1,5 2,5 4 6 10 16 25 35 50 70 95 120 150 185 240
3
6 1)
10 194
16 67 129 502
20 27 75 146
25 36 82 159
35 24 62 154
50 9 50 128
63 17 59 211 3)
80 23 66 236
100 28 62
125 2) 3 25 63
160 22 55
200 20 48 148
225 7 28 58
250 14 35 74
315 7 21 44
400 10 30
500 4
No. 246 246 206 154 124 102 78 78 34 26 26 11 11 9 9
