41
D/GB
Technischer Anhang
Technical annex
Verdrahtungstabellen / Annex wiring tables
Größe/Size 11 650 x 650 x 442
I / A
Ø in mm²
1,5 2,5 4 6 10 16 25 35 50 70 95 120 150 185 240
3
6 1)
10 219
16 75 145 565
20 31 88 164
25 40 93 179
35 27 70 174
50 10 57 144
63 19 67 237 3)
80 25 74 265
100 32 70
125 2) 3 28 71
160 24 62
200 22 54 167
225 8 31 65
250 16 40 83
315 8 24 50
400 11 34
500 5
No. 270 270 226 169 134 114 85 85 68 44 44 18 18 15 15
Beispiel für die Anzahl
der verwendeten Leiter
1 Leiter von außen 1,5 mm²
2 Interner Verbindungsleiter 1,5 mm²
3 Interner Verbindungsleiter 1,5 mm²
4 Interner Verbindungsleiter 1,5 mm²
5 Leiter nach außen 1,5 mm²
für die Berechnung müssen
5 Leiter
berücksichtigt werden
for calculation based on
5 conductors
Example of the number of
conductors used
1 in coming conductor 1.5 mm²
2 internal wire connections 1.5 mm²
3 internal wire connections 1.5 mm²
4 internal wire connections 1.5 mm²
5 out goings conductor 1.5 mm²
1
2
3
4
5
GHG 64....
