Eaton Durant Eclipse Series User Manual

26
PROGRAMMING cont.
Programming Parameters
The programming columns are listed below, column by column. Each block name,
the parameter that it represents, the default value, and the range of values is listed
in the order in which the blocks appear when scrolling up through the column. There
may be some blocks that will cause the installer to wonder should I do anything with
this, or not? A comments section follows each column breakdown. These sections
attempt to provide some practical information that the installer may find helpful in
making programming choices.
Column F - Factors
Block Parameter Range (default Value is Bold)
F1 Count Factor 0 CF1/CF2 select by front panel
Select 1 Count Factor 1 only
2 Count Factor 2 only
3 CF1/CF2 select by inhibit input
F2 Count Factor 1 0.001-99999
1.0000
F3 Count Factor 2 0.001-99999
2.0000
F4 Count Display 0 XXXXXX
Decimal point 1 XXXXX
.X
2 XXXX.XX
3 XXX.XXX
4 XX.XXXX
F5 Rate Display 0 XXXXXX
Decimal point 1 XXXXX.X
2 XXXX.XX
3 XXX.XXX
4 XX.XXXX
F6 Rate Time Unit 1-99999
# of Seconds 60
F7 Rate Smoothing 1-9
Factor
F8 Rate Zero Time 1-9
