Eaton EASY-E4 Series Instruction Leaflet

08/21 IL050020ZU
5/8
Ethernet
EASY-E4-...-..C(X)1 EASY-E4-...-..P
0.5 - 0.7 Nm
3.5 mm
1
2
1
2
1
2
6.5 mm (0.26“)
0.2 - 2.5 mm
2
0.2 - 4 mm
2
0.2 - 2.5 mm
2
AWG 22 - 12
8 mm (0.31“)
0.25 - 1.5 mm
2
8 mm (0.31“)
0.2 - 2.5 mm
2
AWG 24 - 14
8 7 6 5 4 3 2 1
RJ45
EASY-E4-DC-12TC1
(P)
EASY-E4-DC-12TCX1(P)
EASY-E4-AC-12RC1(P)
EASY-E4-AC-12RCX1(P)
EASY-E4-UC-12RC1(P)
EASY-E4-UC-12RCX1(P)
PIN Ethernet 10/100 MBit
8
–
7
–
6
Rx –
5
–
4
–
3
Rx +
2
Tx –
1
Tx +

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
