Eaton EASY-E4 Series Instruction Leaflet

08/21 IL050020ZU
6/8
Power supply
EASY-E4-...-..C(X)1
EASY-E4-...-..P
12, 24 V DC/24 V AC
24 V DC
UC:
DC:
0 V/ N
F1 > 1 A
+24 V 0 V + UC 0 V
EASY-E4-DC-12TC1(P) EASY-E4-DC-12TCX1(P) EASY-E4-UC-12RC1(P) EASY-E4-UC-12RCX1(P)
LNN
EASY-E4-AC-12RC1(P) EASY-E4-AC-12-RCX1(P)
AC:
100 - 240 V AC/DC (cULus 100 - 110 V DC)
L
Ue
6.5 mm (0.26“)
0.2 - 2.5 mm
2
0.2 - 4 mm
2
0.2 - 2.5 mm
2
AWG 22 - 12
0.5 - 0.7 Nm
3.5 mm
8 mm (0.31“)
0.25 - 1.5 mm
2
0.4 x 2.5 mm
8 mm (0.31“)
0.2 - 2.5 mm
2
AWG 24 - 14
0.4 x 2.5 mm

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
