Eaton EASY-E4 Series Instruction Leaflet

08/21 IL050020ZU
7/8
Standard connection
Inputs
Digital inputs
Digital input counter
Analog inputs
12, 24 V DC/24 V AC
24 V DC
0 V/N
InI3I2I10 V
InI3I2I10 V
EASY-E4-DC-12TC1(P)
EASY-E4-DC-12TCX1(P)
EASY-E4-UC-12RC1(P)
EASY-E4-UC-12RCX1(P)
InI3I2I1N
EASY-E4-AC-12RC1(P)
EASY-E4-AC-12RCX1(P)
UC:
DC:
AC:
100 - 240 V AC/DC (cULus 100 - 110 V DC)
L
Ue
L
Ue
N
Ue
I1 - I8
L1 N L1
L2 N L2
L3 N L3
I4I3I2I10 V
I4I3I2I10 V
EASY-E4-DC-12TC1(P)
EASY-E4-DC-12TCX1(P)
EASY-E4-UC-12RC1(P)
EASY-E4-UC-12RCX1(P)
12, 24 V DC
24 V DC
UC:
DC:
0 V/N
24 V DC
0 V
12, 24 V DC
DC:
UC:
0 V+24 V
I8I7I6I5
IA1
IA2
EASY-E4-DC-12TC1(P)
EASY-E4-DC-12TCX1(P)
IA3
IA4
F1 > 1 A
+10 V
0 - 10 V
0 V+UC
I8I7I6I5
IA1
IA2
EASY-E4-UC-12RC1(P)
EASY-E4-UC-12RCX1(P)
IA3
IA4
F1 > 1 A
+10 V
0 - 10 V

Eaton EASY-E4 Series Specifications

General

Type	Programmable Relay
Digital Inputs	Up to 12
Digital Outputs	Up to 8
Display	LCD
Operating Temperature	-25°C to +55°C
Protection Degree	IP20
Storage Temperature	-40°C to +70°C
Supply Voltage	24 V DC, 100-240 V AC
Analog Inputs	4
Outputs	Relay, transistor
Programming	EASY-SOFT-PRO
Communication	Ethernet, Modbus, CANopen
Expansion	Expandable with additional modules
Relative Humidity	5% to 95% (non-condensing)
Standards	IEC/EN 61131-2, UL 508, CSA C22.2 No. 142
