Eaton ELC Series User Manual

- 3 -
Item Specification Note
C0 ~ C99, 100 points (*2) 16-bit counting
up
C100 ~ C199, 100 points (*3)
C200 ~ C219, 20 points (*2) 32-bit counting
up/down
C220 ~ C234, 15 points (*3)
C235 ~ C244, 1 phase 1 input, 10
points (*3)
C246 ~ C249, 1 phase 2 inputs, 4
points (*3)
C Counter
32-bit
high-speed
counting
up/down
C251 ~ C254, 2 phase 2 inputs, 4
points (*3)
Tot al
253
points
Counter
indicated by
CNT (DCNT)
instruction. If
counting
reaches its
target, the C
contact of
the same
No. will be
On.
Initial S0 ~ S9, 10 points (*2)
For zero return
S10 ~ S19, 10 points, used with
IST instruction (*2)
General
purpose
S20 ~ S499, 480 points (*2)
Latched S500 ~ S899, 400 points (*3)
Relay (bit)
S
Step
points
For alarm S900 ~ S1023, 124 points (*3)
Tot al
1,024
points
Used for
SFC
Latched area
setup
Start: D1214
(K500)
End: D1215
(K899)
T Present value in timer T0 ~ T255, 256 points
When timing
reaches the
target, the
contact
continuity of
timer
appears.
C0 ~ C199, 16-bit counter, 200 points
C Present value in counter
C200 ~ C254, 32-bit counter, 53 points
When
counting
reaches the
target, the
contact
continuity of
counter
appears.
General
purpose
D0 ~ D199, 200 points (*2)
D200 ~ D999, 800 points (*3)
Latched
D2000 ~ D9999, 8,000 points (*3)
Special
purpose
D1000 ~ D1999, 1,000 points
ELC data
register
For indirect
indication
E0 ~ E7, F0 ~ F7, 16 points (*1)
Tot al
10,000
points
General
purpose
D0 ~ D199, 200 points (*2)
D200 ~ D999, 800 points (*3)
Latched
D2000 ~ D11999, 10,000 points
(*3)
Special
purpose
D1000 ~ D1999, 1,000 points
D
ELC2 data
register
For indirect
indication
E0 ~ E7, F0 ~ F7, 16 points (*1)
Tot al
12,000
points
Memory
area for data
storage; can
be used for
special
indirect
indication.
ELC file register 0 ~ 9,999 (10,000 points) (*4)
Register (word data)
N/A
ELC2 file register 0 ~ 49999 (50,000 points) (*4)
Extension
register for
data storage
N For main control loop N0 ~ N7, 8 points
Control point
for main
control loop
Index
P For CJ, CALL instructions P0 ~ P255, 256 points
Position
index of CJ
and CALL
