TABLE 5-3. Function Codes (continued)
Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level
Factory
Setting Key Entry Limit
Read Edit Reset Low High
189 Diagnostics Control 189 Database
Version
XX
0 NA NA NA NA NA
• This is the Database Version Number of the firmware.
• XX = Version Number
190 Diagnostics Control 190 PLD
Version
XX
0 NA NA NA NA NA
• This is the Programmable Logic Device (PLD) Version Number
• XX = Programmable Logic Device (PLD) Version Number
191 Diagnostics Control 191 2179
Version
XX
0 NA NA NA NA NA
• This is the 2179 Protocol Version Number
• XX = 2179 Protocol Version Number
192 Diagnostics Control 192 DNP Version
XX
0 NA NA NA NA NA
• This is the DNP Protocol Version Number
• XX = DNP Protocol Version Number
193 Diagnostics Control 193 DNP Checksum
XXXX
0 NA NA NA NA NA
• This is the DNP Protocol Checksum
260 Diagnostics Communications 260 Com Port #1
Tx Messages
XXXXX
0 NA 1 NA NA NA
• This is a count of Transmitted Messages from Com1/Com3.
261 Diagnostics Communications 261 Com Port #1
Rx Messages
XXXXX
0 NA 1 NA NA NA
• This is a count of Received Messages from Com1/Com3.
262 Diagnostics Communications 262 Com Port #1
Rx Errors
XXXXX
0 NA 1 NA NA NA
• This is a count of Receive Errors from Com1/Com3.
263 Diagnostics Communications 263 Com Port #2
Tx Messages
XXXXX
0 NA 1 NA NA NA
• This is a count of Transmitted Messages from Com Port #2
264 Diagnostics Communications 264 Com Port #2
Rx Messages
XXXXX
0 NA 1 NA NA NA
• This is a count of Received Messages from Com Port #2
64
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
