Eaton GridAdvisor Series II Installation, Operation And Maintenance Instructions

Func.
Code
Level 1
Main Menu
Level 2
Sub-Menu
Level 3
Parameter
Security Level Factory
Setting
Key Entry Limit
Read Edit Reset Low High
416 Features Leader/
Follower
416 Leader/Follower
Timeout
XX Seconds
0 2 NA 10 1 60
• The length of time in seconds before the Leader returns to starting tap position if a Follower device does not tap.
417 Features Leader/
Follower
417 Leader/Follower
Retry Delay
XX Seconds
0 2 NA 5 5 60
• The length of time in seconds before the leader retries to initiate a tapping operation if an initial attempt failed.
418 Features Leader/
Follower
418 Leader/Follower
Retries
XX
0 2 NA 3 1 10
• The number of tap retries before the Leader stops retrying taps. Enter the number of times to retry tapping.
420 Features Leader/
Follower
420 Leader/Follower
Monitor
Disabled
NA NA NA NA NA NA
• This is the state of the leader Follower Monitor. It will display either enabled or disabled.
450 Features Alternate
Config
450 Alternate
Configuration
Off
0 2 NA OFF NA NA
• This will turn on Alternate Configurations. The options are:
• Off • On • ARLH • ARLC • P.I.O.
• Selecting "On" will enable the basic Alternate Configuration settings.
• Selecting ARLH will enable the Auto-Restore Local Heartbeat function. This function will revert control settings modified
through SCADA communications back to original settings when a heartbeat signal is lost or discontinued.
• Selecting ARLC will enable the Auto-Restore Local Comms function. This function will revert control settings modified
through SCADA communications back to original settings when a communications signal is lost.
• Selecting P.I.O. will enable Alternate Configuration settings to be enabled or disabled using P.I.O. logic equations.
451 Features Alternate
Config
451 Alternate
Configuration
Inactive
0 NA NA NA NA NA
• This is the state of Alternate Configuration. It will display either Active or Inactive.
TABLE 5-3. Function Codes (continued)
70
CL-6 SERIES CONTROL INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225016EN January 2016
