Table10. Function codes (continued)
Parameter
Unit of
Measure
Security Level
Default Value
Key Entry Limit
To Read To Write To Reset Low High
032 Reverse Load
Current Low
XXX.X Amps
MM-DD-YYYY HH:MM:SS
Amps View NA Operate Reset* NA NA
•This is the lowest value of the load current during reverse power flow since the last
reset, as a demand value, according to the demand time interval at FC 46.
•Date and time of the occurrence of the lowest load current is displayed.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
032 Reverse Load
Current Present
XXX.X Amps
Amps View NA NA NA NA NA
•This is the present value of the load current during reverse power flow, as a demand
value, according to the demand time interval at FC 46.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
033 Power Factor at
Max Reverse kVA
X.XXX
MM-DD-YYYY HH:MM:SS
--- View NA NA
“-----”
(Invalid)
NA NA
•This is the instantaneous power factor of the load at the first occurrence of the maximum
kVA demand value since the last reset, during reverse power flow.
•Note: This parameter is associated with the maximum kVA demand; therefore, it cannot be
reset independent of that parameter.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
033 Power Factor at
Min Reverse kVA
X.XXX
MM-DD-YYYY HH:MM:SS
--- View NA NA
“-----”
(Invalid)
NA NA
•This is the instantaneous power factor of the load at the first occurrence of the minimum
kVA demand value during reverse power flow since last reset.
•Note: This parameter is associated with the minimum kVA demand; therefore, it cannot be
reset independent of that parameter.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
034 Reverse
kVA Load High
XXXX.X kVA
MM-DD-YYYY HH:MM:SS
kVA View NA Operate Reset* NA NA
•This is the highest value of the load kVA during reverse power flow since last reset, as
a demand value, according to the demand time interval at FC 46.
•Date and time of the occurrence of the highest kVA load is displayed.
•The control requires source voltage from a differential or source potential transformer or
from the source voltage calculation (see FC 39) to obtain this parameter. Lack of this
voltage will result in the parameter displaying dashes.
57
INSTALLATION, OPERATION, AND MAINTENANCE INSTRUCTIONS MN225003EN April 2018
CL-7 Voltage Regulator Control
