4. Access to measurements and personalisation data
4.1 Display organisation
4.2 Access to measurements
4.3 Access to UPS set-up and maintenance using the control panel (23)
Press the scroll button (24) (see section 1.3, page 9) to access measurements for voltage, current, frequency, power
output and battery capacity.
◗ Press the scroll button (25) a number of
times to point the UPS set-up or
Maintenance menu
◗ Press the Enter button (27) to get access.
Status and Alarms
Measurements
UPS input measurements
UPS output measurements
Battery measurements
UPS Set-up
Local settings
Output settings
ON/OFF settings
Battery settings
Model
Alarm History
Manual batt test
Led & Buzzer test
Maintenance
LCM
Statistics
Operation limits
Start other UPS
(in parallel)
ESC
IO
27
25
23
UPS SET-UP
MAINTENANCE
