Eaton Pow-R-Line P2R Series User Manual

Instruction Manual Pow-R-Line Retrofit Panelboards
Page 2 Effective: November 2007
P1R & P2R Retrofit Panels
For more information visit: www.EatonCanada.ca
11/2007
Installation Criteria
The Cutler-Hammer Pow-R-Line P1R & P2R panelboards are intended for use in the following
list of panelboard enclosures and which meet the minimum size requirements listed in the table
below.
P1RL & P1RB PANELBOARDS
Main Device Circuits Current
Minimum
Height
(inches)
Minimum
Width
(inches)
Minimum
Depth
(inches)
Lug 18 100 19.5 14.25 4.5
Lug 30 100 26.5 14.25 4.5
Lug 42 100 33.5 14.25 4.5
Lug 18 225 22 14.25 4.5
Lug 30 225 28 14.25 4.5
Lug 42 225 34 14.25 4.5
Breaker (BAB) 18 60-100 19.5 14.25 4.5
Breaker (BAB) 30 60-100 26.5 14.25 4.5
Breaker (BAB) 42 60-100 33.5 14.25 4.5
Breaker (E or F Frame) 18 60-225 30 14.25 4.5
Breaker (E or F Frame) 30 60-225 36 14.25 4.5
Breaker (E or F Frame) 42 60-225 42 14.25 4.5
Lug 24 400 48 20.0 5.75
Lug 30 400 48 20.0 5.75
Lug 42 400 48 20.0 5.75
P2RL & P2RB PANELBOARDS
Main Device Circuits Current
Minimum
Height (in)
Minimum
Width (in)
Minimum
Depth (in)
Lug 18 100 19.5 14.25 4.75
Lug 30 100 26.5 14.25 4.75
Lug 42 100 33.5 14.25 4.75
Lug 18 225 22 14.25 4.75
Lug 30 225 28 14.25 4.75
Lug 42 225 34 14.25 4.75
Breaker (GBH, GHB) 18 60-100 19.5 14.25 4.75
Breaker (GBH, GHB) 30 60-100 26.5 14.25 4.75
Breaker (GBH, GHB) 42 60-100 33.5 14.25 4.75
Breaker (E or F Frame) 18 60-225 30 14.25 4.75
Breaker (E or F Frame) 30 60-225 36 14.25 4.75
Breaker (E or F Frame) 42 60-225 42 14.25 4.75
Lug 24 400 48 20.0 5.75
Lug 30 400 48 20.0 5.75
Lug 42 400 48 20.0 5.75
