Eaton T5B Series User Manual

Emergency On Call Service: Local representative (www.eaton.eu/aftersales) or +49 (0)180 5223822 (de, en) 3/4
07/16 IL03801009Z
T5B…/I4(-RT)
T5B…/I4/SVB(-SW)
Components drawn in broken lines are not included in the scope of delivery.
Gestrichelt gezeichnete Komponenten gehören nicht zum Lieferumfang.
Les éléments représentés en pointillés ne font pas partie de la fourniture.
Los componentes dibujados en líneas discontinuas no están incluídos en
el suministro.
Gil apparechi contrassegnati con un tratteggio con fanno parte della fornitura.
Заштрихованные компоненты не входят в объем поставки.
ON
OFF
ON
OFF
4 x ST 3.9 x 19
1 Nm
(8.85 lb-in)
1 Nm
(8.85 lb-in)
1 Nm (8.85 lb-in)
1 x ST 3.9 x 25
1 Nm (8.85 lb-in)
ZFS...P3
en
de
fr
es
it
zh
ru
ON
OFF
ON
OFF
ZFS...P3
DE-P3
X
Z
Y
4 x ST 3.9 x 19
1 Nm (8.85 lb-in)
1 x ST 3.9 x 25
1 Nm (8.85 lb-in)
T5(B)-1-…
T5(B)-3-…
T5(B)-2-…
T5(B)-4-…
1 Nm
(8.85 lb-in)
1 Nm
(8.85 lb-in)
4 x ST 3.9 x 19
1 Nm (8.85 lb-in)
T5…/I5(-RT)
T5…/I5/SVB(-SW)
c
b
ON
OFF
a
[mm] T5B-1(2) T5B-3(4) T5-1(2) T5-3(4)
a160 160 200 200
b240 240 280 280
c95160 125 160
[in]T5B-1(2) T5B-3(4)T5-1(2) T5-3(4)
a6.29 6.297.877.87
b9.45 9.45 11.0211.02
c3.74 6.294.926.29
